LDPE/LLDPE Heavy-Duty Film Blowing Machine
Low base type extruder, heavy duty steel structure. Helical reduction gear box with Sweden made thrust bearing, oil pump and oil cooler for extra lubrication affect. Barrier fight screw design or grooved feeder extruder to ensure the best mixing result as well as stable and sufficient extrusion output capacity.
- Heavy-duty Film for Construction and Agricultural Applications
- Tubular lay flat width: From 40 mm to 7 M
- MONO LAYER, TWO LAYER, THREE LAYER & FIVE LAYER
SINGLE COLOR, DOUBLE COLOR, UP TO 4 COLOR
Specification
| Machine Model | FK/AFS-150-4250-G |
|---|---|
| Resin | LDPE(≧50%)+LLDPE(≦50%), 100% Recycle |
| Film Size | 6100 mm (Max. Layflat)/ with gusseting upto 3050 mm width |
| Film Thickness | 150 - 200 μm |
| Extruder | Ø150 mm, L/D=30 |
| Main Drive | 300 HP AC motor with vector inverter x 1 set |
| Extrusion Output | 550-600 kgs/hr for LDPE 500-550 kgs/hr for LLDPE |
| Line Speed | 2-20 M/min |
| Extruding Die Size | Ø1600 mm |
| Tower Height | 15500 mm |
| Haul Off Unit | with nip roller 4250 mm width |
| Winder | Single station, 4 rolls type design Semi auto surface friction type with film cutting by air knife |
*AII specifications, design and characteristics shown above are object to change without prior notice.
