BFS Series Single Layer Blown Film Line
- Custom Designed Co Extrusion Blown Film Line
- Tubular lay flat width:From 40 mm to 7 M
MONO LAYER, TWO LAYER, THREE LAYER & FIVE LAYER
SINGLE COLOR, DOUBLE COLOR, UP TO 4 COLOR.
Specification
| Machine Model | FK/BFS-70-1800 |
|---|---|
| Resin | LDPE/LLDPE |
| Film Size | 1700 mm (Max.) |
| Film Thickness | 0.025 - 0.1 mm |
| Extruder | Ø70 mm, L/D=30 Grooved feeder |
| Main Drive | 75 HP AC motor with inverter control |
| Extrusion Output | 180 kgs/hr |
| Extruding Die Size | Ø300 mm |
| Line Speed | 30-80 M/min |
| Tower Height | 7000 mm |
| Haul Off Unit | with nip roller 1800 mm width |
| Winder | Back to back station/Auto surface friction type/Film cutting by air knife |
*AII specifications, design and characteristics shown above are object to change without prior notice.
