| 塑料 |
HDPE (Marlex 50100) |
| 產品 |
20/25 Liter jerry can |
| 產能 |
120 pcs/hr |
| 押出機馬力 |
75 hp AC motor with inverter control |
| 押出機螺桿 |
75 mm dia., L/D=30:1 |
| 押出量 |
170 kgs/hr (for HDPE virgin grade) |
| 模頭設計 |
Single head |
| 膜嘴尺寸 |
180 mm dia. (max.) |
| 油液壓馬達 |
25 hp induction motor |
| 夾模板( H x W ) | 720 mm x 550 mm |
| 夾模力 | 30 tons (300 KN) (max) |
| 夾模距離 | 480 ～1000 mm |
| 模具厚度 | 500 mm (Min) |
| 壓力值 | 180kg/c㎡(max.) |
| 冷卻系統 | Two station, one is combined with deflash position; |
| 除胚裝置 | Top/bottom and handle deflash |
