| Resin |
ABS , 70% VG + 30% RG |
| Products |
Sheet for forming purpose used for refrigerator |
| Products width |
1800mm (max.) x 1 sheet |
| Products thickness |
0.6mm - 2.5mm |
| Line speed |
0.6～6.0 m/min. Mechanical possibility |
| Extrusion output |
60kg/hr |
| Extruder |
100mmφ Screw, L/D=32:1 x1 set for A layer 150mmφ Screw, L/D=32:1 x1 set for B layer |
| Main drive |
125 HP, extrusion output 300 kg/hr 200 KW, extrusion output 500 kg/hr |
| Extrusion output |
800 kg/hr (max., based on 100% virgin grade) |
| Extrusion die |
1 set, FKI-TYPE, Co-extrusion type |
| Polishing roll unit |
Up-stack, 90 degree configuration |
| Polishing roller |
500mmφ x 2100mm width x 3 pcs |
| Heat and cool system |
Three (3) individual closed loop system x 1 set |
| Haul-off unit |
Main haul-off roller |
| Haul-off unit |
Main haul-off roller |
