| Resin |
PA6, PA66, PP |
| Product |
Sticky buckle strap |
| Product thickness |
0.4-2.0 mm |
| Product width |
320 mm (trimmed) |
| Capacity |
130 kg/hr for PA |
| Line speed |
30 m/min |
| Extruder |
65 mm dia , L/D=34 |
| Main drive |
75 HP A.C. invertor motor |
| Extrusion die |
FKI made |
| Screen changer |
hydraulic type |
| Line Speed |
2 - 12 M/Min. (Max.) |
| Polishing roller |
φ 254 MM x 556 MM wide x 1 φ 254 MM x 500 MM wide x 2 |
| Gap adjustment |
Driven by hydraulic unit /Controlled by Servo motor |
| Take off unit |
φ 150 M/M dia. x 500 M/M wide x 2 |
| Winder |
turret type |
| Electric cabinet |
one set |
